Description
The CONTEC CT250 is one of the most powerful floor planers on the market. With a 180 mm (7 in) drum diameter and a 57 mm (2.2 in) cutter/flail diameter, it can handle any surface. It offers dust - free operation, a robust and precise construction for reliable performance. There is an extensive selection of cutters, and the cutter drum assemblies have a long lifespan. An optional integrated drive is available for easier operation.
This machine has a 10 - inch (250mm) working width, which means more productivity per pass. It comes in both gas and electric models to suit your needs. The optional drive unit makes operating the CT250 a breeze.
Technical Specs:
- CTPCT250:
- Maximum Working Width: 10' (250mm)
- Motor: 9 kW (12 hp) 230 V, 60 Hz, 3 Phase, 26 Amps
- Dimensions (H x L x W): 39 x 41 x 17 in
- Weight: 298 lbs
- Diameter of Diamond Blade: 7.9 inch
- CTPCT250P:
- Maximum Working Width: 10' (250mm)
- Motor: 9 kW (12 hp) Gas
- Dimensions (H x L x W): 39 x 41 x 17 in
- Weight: 298 lbs
- Diameter of Diamond Blade: 7.9 inch
Applications include surface texturing, scarifying, planing, grooving, cleaning, de - scaling, and removal of road markings, coatings, and membranes.
Using the CONTEC CT250 floor scarifier/planer is quite straightforward. First, decide whether you want to use the gas or electric model according to your needs. Make sure to connect or fuel it properly before starting.
When you start the machine, the large drum and cutters will start working on the surface. Move the machine steadily over the area you want to treat. Thanks to its 10 - inch working width, you can cover a large area in each pass.
If you've chosen the optional drive unit, it will make moving the CT250 much easier.
Here are some important notes. Always wear proper safety gear, like goggles and a dust mask, because even though it's a dust - free operation, some fine particles might still be present. Don't try to use it on surfaces that are too hard or uneven for its capacity.
For maintenance, regularly check the cutters and replace them when they're worn out. Keep the machine clean after each use. If it's the gas model, make sure to follow the fuel storage and handling guidelines. And for the electric model, check the power cords for any damage.
