Meta. Ergonomic Bench Top Tilters boost efficiency and cut down fatigue and injury risks by positioning work at a better ergonomic angle. They can tilt loads up to 1,000 pounds from 0 to 45 degrees. These heavy - duty steel tilters can be attached to most industrial table tops, work benches, and mobile lift tables with enough load capacity and surface size. A pendent hand control with UP and DOWN push buttons on an 8 - foot cord maximizes operator convenience. They come with a flat base plate having slotted holes for installation and are colored royal blue. There are different types: The manually adjustable tilter, ideal for applications needing occasional tilt angle changes, is adjustable at 15, 30, or 45 degrees, and a three - inch retaining lip stops loads up to 600 pounds from sliding off. The electro - mechanical internal operating mechanism can lift up to 500 pounds to a 45 - degree angle from a five - inch lowered height. The external operating mechanism can lift up to 1,000 pounds to a 45 - degree angle from a five - inch lowered height. These tilters have a sliding top that tilts within its base frame, offering higher stability than conventional hinge - style tilters. Check out the models below with details on platform size, capacity, tilt degree, operation, and weight.
Using your Bench Top Tilter is easy. First, make sure it's properly attached to a suitable table top, workbench, or mobile lift table. You can use the pendent hand control on the 8 - foot cord to tilt the load. For the manually adjustable tilter, just set it to the desired angle of 15, 30, or 45 degrees when you need to change the tilt. When loading, don't exceed the maximum capacity of each model. For models with a retaining lip, it helps keep lighter loads in place, but still be careful. As for maintenance, keep the tilter clean and free from debris. Check the operating mechanisms regularly for any signs of wear or damage. If you notice anything wrong, stop using it and have it inspected. And remember, these tilters are painted royal blue, so avoid any harsh chemicals that could damage the paint.
