Description
The CC5555GK is a high-performance rear pivot, three-speed walk-behind saw. It features a 14' to 36' blade capacity and is powered by a 57HP Kubota gas engine. The Kubota® liquid-cooled gasoline WG1605 LSI engine fully complies with EPA regulations. It comes with a Murphy PV480, 4.3' controller display. The saw is easy to maneuver with a rear-pivot self-propelled drive and a 4-position handlebar setup (0°, 15°, 30°, 45°). A 3-speed gear box is standard, and it has a pull/twist-lock for rear positraction and transmission neutral. The quick release blade shaft & flange makes blade changes a breeze. It has a heavy-duty crated steel frame base for increased rigidity and a square tube skeletal upright frame for improved strength. Removable access panels allow for easy routine maintenance. The electronic depth display and stop function provide precision cutting, and the toggle switch throttle control gives you smooth operation. Specifications include various max depths of cut depending on blade size, an arbor size of 1' with single drive pin, 7 belts for blade shaft drive, right or left blade mounting, an electro-hydraulic pump for blade raise/lower, a 5.5-gallon fuel tank with digital fuel display, an Eaton Model 7 transmission, and a drive speed of 0 - 368 feet per minute. It also includes a blade shaft tachometer, hour meter, frame lift, cutting depth indicator, quick disconnect blade flanges, telescoping front pointer, GM gel battery, and removable panels.
Using the CC5555GK walk-behind saw is straightforward. First, make sure the fuel tank is filled with gasoline. The digital fuel display will show you the fuel level. Turn on the engine and use the toggle switch throttle control to adjust the speed. The 4 - position handlebar can be set at 0°, 15°, 30°, or 45° according to your comfort. To change the blade, use the quick release blade shaft & flange. You can choose the blade size based on your cutting needs, and the electronic depth display will help you set the cutting depth accurately. When it comes to maintenance, regularly check the belts of the blade shaft drive. If they are worn out, replace them. The removable access panels make it easy to access the parts for routine checks. Keep the fuel tank clean and use high - quality gasoline. Store the saw in a dry place when not in use to prevent rusting. Always follow the safety instructions and wear appropriate protective gear when operating the saw.
