Aardwolf Slab Lifter 75 Rollers

Aardwolf Slab Lifter 75: Ideal for Lifting 3cm Slabs

Features

• Compact Size: With its compact construction, the Aardwolf Slab Lifter AL75 can lift closely packed stone slabs from racks and containers. It has no trouble with lower height slabs beside taller ones, unlike scissor clamps.
• Versatile Use: Perfect for construction work. Since the clamping mechanism is at the front of the slab, it allows panels to be placed right up against walls.
• High Safety: Only a small movement of the slab is needed to engage and grip it, usually well below the over - balance angle, eliminating risks to the operator.
• Secure Grip: The Aardwolf clamps firmly hold marble and granite slabs. The Aardwolf Slab Lifter AL75 has a force - multiplying factor of about 2.5 to 1.

Specifications

Model	Grip Range	Working Load Limit	Net Weight	Gross Weight	Packing Dimensions
Lifter 30 Wide	0.2'' - 1''	2646	45	47	17.3''x6.3x14.2''
Lifter 50	0.4'' - 2''	2646	42	44	15''x8.3''x9''
Lifter 50 - B	0.4'' - 2''	2646	53	55	22.8''x7.3''x12.2''
Lifter 60	0.6'' - 2''	2646	55	57	16.5''x9''x9.8''
Lifter 75	1'' - 3''	2646	55	57	16.5''x9''x9.8''
Lifter 50 (Auto)	0.4'' - 2''	2646	42	44	15''x8.3''x9''
Lifter 60 (Auto)	0.6'' - 2''	2646	55	57	16.5''x9''x9.8''
Lifter 75(Auto)	1'' - 3''	2646	55	57	16.5''x9''x9.8''

Using the Aardwolf Slab Lifter 75 is quite simple. First, make sure the slab's thickness is within the grip range of the model you're using. Place the lifter on the slab and make a small movement to engage the clamps. Once the clamps grip the slab firmly, you can start lifting. When you lower the slab to the ground, the spring - loaded latch will automatically release the lifter. Here are some important notes. Always check the working load limit and don't exceed it to avoid any accidents. Also, keep the over - balance angle in mind and make sure the small movement to engage the clamps is well below this angle. For maintenance, regularly clean the lifter to prevent dirt and debris from affecting its performance. Check the clamps for any signs of wear and tear, and if you notice any issues, have them repaired or replaced promptly. This way, your Aardwolf Slab Lifter 75 will serve you well for a long time.
