The Abaco Pro-M3 One-Stop A-Frame is the ultimate solution for storing and transporting heavy stone slabs in warehouses, factories, and construction sites. With a focus on flexibility and stability, this A-frame system can be easily disassembled into components, making it a breeze to pack and transport. It offers a versatile option for handling heavy-duty stone slabs, keeping them secure during storage and transit.
**General Information:**
- **Versatile Design:** Available in three versions - OSA7247PRO-M3, OSA7263PRO-M3, and OSA8763PRO-M3 - to meet different storage and handling needs.
- **Easy Disassembly:** Can be taken apart into separate pieces for convenient transportation and storage.
- **Adjustable Frame:** The A-frame can be detached from the base frame for flexible adjustments and operations.
**Features & Benefits:**
- **Dual-Component Structure:** Composed of a base frame and A-frame, along with ratchet-securing bars for enhanced stability and material protection.
- **Heavy-Duty Casters:** Four heavy-duty caster wheels (two swivel casters) support the base frame, providing easy maneuverability and a stable load capacity of up to 4,400 lbs (2,000 kg) when using casters.
- **Ratchet Securing Bars:** Adjustable ratchet securing bars with top straps and bottom slots firmly hold stone slabs of various sizes in place.
- **Rubber Protection Strips:** Black and white rubber strips are evenly placed on the A-frame to prevent scratches and damage to the slabs during storage and transport.
- **High Load Capacity:** When stationary (without casters), each model can support a load capacity of up to 30,800 lbs (14,000 kg), ideal for large and heavy slabs.
**Product Specifications:**
- **OSA7247PRO-M3:** Length 73 15/16' (1878 mm), Width 43 5/16' (1100 mm), Height 62 15/16' (1600 mm), Weight 345.4 lbs (157 kg), Rolling Capacity 4,400 lbs (2,000 kg), Stationary Capacity 30,800 lbs (14,000 kg), Lifting Capacity with Eyelets 5,500 lbs (2,500 kg).
- **OSA7263PRO-M3:** Length 73 15/16' (1878 mm), Width 43 5/16' (1100 mm), Height 78 3/4' (2000 mm), Weight 363 lbs (165 kg), Rolling Capacity 4,400 lbs (2,000 kg), Stationary Capacity 30,800 lbs (14,000 kg), Lifting Capacity with Eyelets 5,500 lbs (2,500 kg).
- **OSA8763PRO-M3:** Length 88 1/2' (2248 mm), Width 43 5/16' (1100 mm), Height 78 1/2' (1994 mm), Weight 437.8 lbs (199 kg), Rolling Capacity 4,400 lbs (2,000 kg), Stationary Capacity 30,800 lbs (14,000 kg), Lifting Capacity with Eyelets 5,500 lbs (2,500 kg).
The Abaco Pro-M3 One-Stop A-Frame is an innovative and reliable tool for professionals in need of an efficient material handling system. Order yours today and enjoy top-notch storage efficiency and safety.
Using the Abaco Pro-M3 One-Stop A-Frame is quite straightforward. First, assemble the base frame and attach the A-frame according to the instructions. If you need to move the frame, use the heavy-duty casters. Just make sure the load doesn't exceed the rolling capacity of 4,400 lbs (2,000 kg). When you place the stone slabs on the A-frame, use the adjustable ratchet securing bars with top straps and bottom slots to hold them firmly in place. This will keep the slabs stable during storage and transport.
Here are some important things to keep in mind. Don't overload the A-frame. When it's stationary, make sure the load doesn't go beyond the stationary capacity of 30,800 lbs (14,000 kg). Also, when lifting with the eyelets, the load should not exceed 5,500 lbs (2,500 kg).
For maintenance, regularly check the ratchet-securing bars, casters, and rubber protection strips. If the rubber strips are worn out, replace them to keep protecting the stone slabs from scratches. Keep the frame clean and dry to prevent rusting. If you need to store the A-frame for a long time, disassemble it into components and store them in a dry place. This way, your Abaco Pro-M3 One-Stop A-Frame will serve you well for a long time.
